1-2 Stål "One-Piece" K, METRISK "K"
METRISK RSL/S – SM10K
Från: 34,00 kr
Presskoppling utan mutter och skärring.
Slangstuds RSL
Slangstuds RSS
| Artikelnummer | DN | Tum | Dash | C | A | B |
| SM10K0406 | 6 | 1/4″ | 04 | 6 | 28 | 22 |
| SM10K0408 | 6 | 1/4″ | 04 | 8 | 30,5 | 24 |
| SM10K0410 | 6 | 1/4″ | 04 | 10 | 33 | 27 |
| SM10K0510 | 8 | 5/16″ | 05 | 10 | 30,5 | 24 |
| SM10K0610 | 10 | 3/8″ | 06 | 10 | 30,5 | 24 |
| SM10K0612 | 10 | 3/8″ | 06 | 12 | 30,5 | 24 |
| SM10K0815 | 12 | 1/2″ | 08 | 15 | 32 | 25 |
| SM10K0816 | 12 | 1/2″ | 08 | 16 | 37 | 30 |
| SM10K1018 | 16 | 5/8″ | 10 | 18 | 34 | 27 |
| SM10K1020 | 16 | 5/8″ | 10 | 20 | 44 | 37 |
| SM10K1218 | 19 | 3/4″ | 12 | 18 | 34,5 | 27 |
| SM10K1220 | 19 | 3/4″ | 12 | 20 | 44,5 | 36 |
| SM10K1222 | 19 | 3/4″ | 12 | 22 | 36,5 | 28 |
| SM10K1225 | 19 | 3/4″ | 12 | 25 | 49,5 | 41 |
| SM10K1625 | 25 | 1″ | 16 | 25 | 51 | 41 |
| SM10K1628 | 25 | 1″ | 16 | 28 | 40 | 30 |
| SM10K1630 | 25 | 1″ | 16 | 30 | 54 | 44 |
| Vikt | N/A |
|---|---|
| Slangdimension | |
| Rördiameter | 6mm, 8mm, 10mm, 12mm, 15mm, 16mm, 18mm, 20mm, 22mm, 25mm, 28mm, 30mm |
